50mm Linear Motion Ball Screw for Machine Tool
50mm Linear Motion Ball Screw for Machine Tool

50mm Linear Motion Ball Screw for Machine Tool

  • Payment Type: L/C,T/T,D/P
  • Incoterm: FOB,CFR,CIF,EXW,FAS,FCA,CPT,CIP,DEQ,DDP,DDU,Express Delivery,DAF,DES
  • Min. Order: 5 Piece/Pieces
  • Transportation: Ocean,Land,Air,Express
  • Port: Shanghai,Dalian,Zhoushan
  • $29.99-299.99 /Piece/Pieces

Sample:
$300.00 /Piece/Pieces, 10 Piece/Pieces (Max. Order)
PRODUCT ATTRIBUTES
Overview
Product Attributes

Model No.GD5006-3-186-199-C3

BrandHOJAMA

StatusNew

Warranty Period1.5 Years

Applicable IndustryEnergy &Amp; Mining, Other, Manufacturing Plant, Machinery Repair Shops, Food &Amp; Beverage Factory

Out-of-warranty ServiceVideo Technical Support, Online Support, Spare Parts

Where To Provide Local Services (in Which Countries Are There Overseas Service Outlets)None

Showroom Location (in Which Countries Are There Sample Rooms Overseas)None

Video Factory InspectionProvided

Mechanical Test ReportProvided

Marketing TypeOrdinary Product

Core Component Warranty Period1 Year

Core ComponentsEngine, Plc, Bearing, Gearbox, Motor, Gear, Pump

Processing TechnologyMilled Thread

Place Of OriginChina

Overview
Supply Ability & Additional Information

PackagingWooden box

Productivity30000 sets/month

TransportationOcean,Land,Air,Express

Place of OriginChina

Supply Ability30000 sets/month

CertificateISO9001:2015

PortShanghai,Dalian,Zhoushan

Payment TypeL/C,T/T,D/P

IncotermFOB,CFR,CIF,EXW,FAS,FCA,CPT,CIP,DEQ,DDP,DDU,Express Delivery,DAF,DES

Packaging & Delivery
Selling Units: Piece/Pieces
Single package size: 95cm*10cm*10cm
Single gross weight: 4.5kg
Package Type: Wooden box
Picture Example:
Product Description

GD5006-3-186-199-C3---Hojama high-efficiency 50mm Diameter Ball Screw

Chromium Plating for Ball Screw Surface Treatment

1. Enhancement of Wear Resistance

The chromium plating layer exhibits high hardness and a low friction coefficient, which significantly enhances the wear resistance of ball screw assemblies and reduces surface wear during prolonged operation.

2. Improvement of Corrosion Resistance

The chromium layer exhibits chemical stability in various environments, including humid air, alkaline solutions, nitric acid, sulfides, carbonates, and organic acids. It forms a dense protective barrier, enhancing the linear motion ball screw’s corrosion resistance in harsh conditions.

3. Strengthening of Hardness and Load-Bearing Capacity

After chromium plating, the surface hardness of ball screw kits can reach 55-65 HRC (Rockwell hardness), far exceeding that of ordinary steel. This enables them to withstand heavier loads, improving structural strength and durability.

4. Optimization of Appearance Texture

The chromium plating layer has excellent light reflectivity, giving the ball screw surface a bright and aesthetic metallic texture, thus enhancing its appearance quality.

5. Restoration of Dimensional Deviation

The chromium plating process can compensate for dimensional loss caused by wear or machining errors in linear ball screws, restoring their precision specifications.

6. Enhancement of High-Temperature Resistance

The chromium layer has excellent thermal stability: it does not discolor below 480°C, starts to oxidize above 500°C, and only shows significant hardness reduction at 700°C. This ensures the ball screw maintains stable performance within a certain temperature range.

7. Prolongation of Service Life

Chromium plating treatment significantly extends the service cycle of high-accuracy ball screws, reducing equipment maintenance and replacement frequency.
?

Advantages of Hojama high-performance ball screws:

1.? High precision

We can provide you with various accuracy grades for linear ball screws, C3 and C5. And the repeatable position accuracy is up to 8μm.

2. Low friction

Hojama ball screws adopt a unique recirculating ball system. The balls roll within the raceways between the screw shaft and the nut, replacing traditional sliding friction with rolling friction and significantly reducing the friction coefficient.

3. Smooth Operation

Due to its Low friction, the ball screw is running smoothly during the operation.
?
Hojama is addicted to ball screw manufacturing, our ball screw types include mini ball screws, Precision Ball Screws, linear rails, Linear Modules, Lead Screws, and Ball Splines. Welcome to discuss how to update your equipment with our ball screw set.
